Anritsu 681XXC - Chapter 7 Use With Other Instruments; 7-1 INTRODUCTION

Table of Contents
7-1 INTRODUCTION ...................7-3
7-2 MASTER-SLAVE OPERATION ...........7-4
Connecting the Instruments ...........7-4
Initiating Master-Slave Operation ........7-5
Master-Slave Operation .............7-7
Master-Slave Operation in VNA Mode ......7-7
Terminating Master-Slave Operation .......7-9
7-3 USE WITH A 56100A SCALAR NETWORK
ANALYZER .....................7-10
Connecting the 681XXC to the 56100A .....7-10
7-4 USE WITH A 360B VECTOR NETWORK
ANALYZER .....................7-12
Connecting the 681XXC to the 360B ......7-12
Modes of Operation...............7-13
Source Lock Mode ...............7-13
Tracking Mode .................7-15
7-5 USE WITH A HP8757D SCALAR NETWORK
ANALYZER .....................7-16
Connecting the 681XXC to the HP8757D ....7-16
Setting Up the 681XXC.............7-17
Initiating HP8757D SNA Operation.......7-19
Chapter 7
Use With Other Instruments
