3-16 681XXC OM
Table 3-1. Reset (Default) Paramenters (1 of 2)
681XXC
MODEL
NUMBER
FREQUENCY PARAMETERS (GHz)
F0 F1 F2 F3 F4 F5 F6 F7 F8 F9 M0 M1 M2 M3 M4 M5 M6 M7 M8 M9 DF
68117C 3.5 2.0 8.4 2.0 5.0 8.0 8.4 8.4 8.4 8.4 3.5 2.0 8.4 2.0 5.0 8.0 8.4 8.4 8.4 8.4 1.0
68137C 3.5 2.0 20.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 3.5 2.0 20.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 1.0
68147C 3.5 2.0 20.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 3.5 2.0 20.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 1.0
68167C 3.5 2.0 40.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 3.5 2.0 40.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 1.0
68177C 3.5 2.0 50.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 3.5 2.0 50.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 1.0
68187C 3.5 2.0 60.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 3.5 2.0 60.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 1.0
68197C 3.5 2.0 65.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 3.5 2.0 65.0 2.0 5.0 8.0 11.0 14.0 17.0 20.0 1.0
681XXC
MODEL
NUMBER
POWER LEVEL PARAMETERS (dBm)
L0 L1 L2 L3 L4 L5 L6 L7 L8 L9
68117C +1.0 0.0 –1.0 –2.0 –3.0 –4.0 –5.0 –6.0 –7.0 –8.0
68137C +1.0 0.0 –1.0 –2.0 –3.0 –4.0 –5.0 –6.0 –7.0 –8.0
68147C +1.0 0.0 –1.0 –2.0 –3.0 –4.0 –5.0 –6.0 –7.0 –8.0
68167C +1.0 0.0 –1.0 –2.0 –3.0 –4.0 –5.0 –6.0 –7.0 –8.0
68177C +1.0 0.0 –1.0 –2.0 –3.0 –4.0 –5.0 –6.0 –7.0 –8.0
68187C +1.0 0.0 –1.0 –2.0 –3.0 –4.0 –5.0 –6.0 –7.0 –8.0
68197C +1.0 0.0 –1.0 –2.0 –3.0 –4.0 –5.0 –6.0 –7.0 –8.0
LOCAL (FRONT RESET (DEFAULT)
PANEL) OPERATION PARAMETERS
