A-3 Test Records for Spectrum Analyzer Verification Appendix A — Test Records
A-10 PN: 10580-00324 Rev. N S412E MM
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-14. Spectrum Analyzer Amplitude Accuracy Across Frequency (1 of 5)
Freq
(MHz)
Test Power
(dBm)
Reference
Level
Setting
(dBm)
Atten
Level
Setting
(dB)
Pre-Amp
Setting
Marker 1
Reading
(dBm)
Dev
(dB)
Spec
(dB)
0.1
–50 –40 15 On ±1.25
–30 –20 0 Off ±1.25
–30 –20 5 Off ±1.25
–30 –20 10 Off ±1.25
–30 –20 20 Off ±1.25
–2030Off ±1.25
–2040Off ±1.25
–2050Off ±1.25
–2055Off ±1.25
10.1
–50 –40 15 On ±1.25
–30 –20 0 Off ±1.25
–30 –20 5 Off ±1.25
–30 –20 10 Off ±1.25
–30 –20 20 Off ±1.25
–2030Off ±1.25
–2040Off ±1.25
–2050Off ±1.25
–2055Off ±1.25
