Anritsu S412E - 1-2 Instrument Description

Chapter 1 — General Information 1-5 Anritsu Customer Service Centers
S412E MM PN: 10580-00324 Rev. N 1-3
1-5 Anritsu Customer Service Centers
For the latest service and sales information in your area, please visit the following URL:
http://www.anritsu.com/contact.asp
Choose a country for regional contact information.
1-6 Recommended Test Equipment
The following test equipment is recommended for use in testing and maintaining the S412E. Table 1-1 is a list
of test equipment that is required for verifying the vector network analyzer functions and associated VNA
options. Table 1-2 is a list of test equipment that is required for verifying the spectrum analyzer functions and
associated SPA options. Table 1-3 is a list of test equipment that is required to verify the signal generator and
Table 1-4 is a list of test equipment that is required to verify the S412E options.
Table 1-1. Recommended Test Equipment for Vector Network Analyzer Verification
Equipment Critical Specification
Recommended
Manufacturer/Model
Frequency Counter Frequency: 10 Hz to 6 GHz Anritsu Model MF2412C
Frequency Reference Frequency: 10 MHz Symmetricom Model
RubiSource T&M
Open/Short/Load Frequency: DC to 6 GHz
Connector: N(m)
Anritsu Model OSLN50-1
Open/Short/Load Frequency: DC to 6 GHz
Connector: N(f)
Anritsu Model OSLNF50-1
RF Coaxial Cable Frequency: DC to 18 GHz
Impedance: 50 Ohm
Connector: N(m) to N(m)
Anritsu Model 15NN50-1.5C
6 dB Offset Termination Frequency: DC to 6 GHz
Connector: N(m)
Anritsu Model SC7424
20 dB Offset Termination Frequency: DC to 6 GHz
Connector: N(m)
Anritsu Model SC7423
Coaxial Cable Connector: BNC(m) to BNC(m)
Impedance: 50 Ohm
Anritsu p/n 2000-1627-R
Interface Cable USB A to USB mini Anritsu p/n 3-2000-1498
Test Software VNA Instrument Test Verification Software Anritsu p/n 2300-535
PC Controller Microsoft Windows XP or Windows 7, 1 GB
RAM, at least 20 MB of free hard disk
space, USB 2.0 Type A port with National
Instruments VISA
a
Version 3.6 or later
loaded
a. National Instrument VISA license is available from National Instruments as a stand-alone software package or as part of
National Instruments GPIB adapter hardware package. Please contact National Instruments for details.
Any
