1-6 Recommended Test Equipment Chapter 1 — General Information
1-4 PN: 10580-00324 Rev. N S412E MM
Table 1-2. Recommended Test Equipment for Spectrum Analyzer Verification
Equipment Critical Specification
Recommended
Manufacturer/Model
Frequency Reference Frequency: 10 MHz Symmetricom Model
RubiSource T&M
Synthesized Signal Generator Frequency: 0.1 Hz to 20 GHz
Power Ouput: +16 dBm
Step attenuator installed
Anritsu Model MG3692B or
MG3692C with Options 2A, 3, 4
and 22 (Quantity 2)
Power Meter Power Range: –70 dBm to +20 dBm Anritsu Model ML2438A
Power Sensor Frequency:
100 kHz to 18 GHz
Power Range:
–67dBm to +20dBm
Anritsu Model SC7400
(Quantity 2)
Power Sensor Frequency:
100 kHz to 18 GHz
Power Range:
–67dBm to +20dBm
Anritsu Model MA2442D
Adapter Frequency: DC to 18 GHz
Connector: K(m) to N(f)
Anritsu Model 34RKNF50
Adapter Frequency: DC to 18 GHz
Connector: N(m) to N(m)
Anritsu Model 34NN50A
RF Coaxial Cable Frequency: DC to 18 GHz
Connector: N(m) to N(m)
Anritsu Model 15NN50-1.5C
(Quantity 2)
Coaxial Cable Impedance: 50 Ohm
Connector: BNC(m) to BNC(m)
Anritsu Model 2000-1627-R
(Quantity 3)
Termination Frequency: DC to 18 GHz
Impedance: 50 Ohm
Connector: N(m)
Anritsu Model 28N50-2
Power Splitter Frequency: DC to 18 GHz
Connector: N(f)
Aeroflex/Weinschel Model 1870A
Fixed Attenuator Frequency: DC to 18 GHz
Attenuation: 2 dB
Aeroflex/Weinschel Model 44-2
(Quantity 2)
Fixed Attenuator Frequency: DC to 18 GHz
Attenuation: 6 dB
Aeroflex/Weinschel Model 44-6
(Quantity 2)
Fixed Attenuator Frequency: DC to 18 GHz
Attenuation: 10 dB
Aeroflex/Weinschel Model 44-10
Fixed Attenuator Frequency: DC to 18 GHz
Attenuation: 20 dB
Aeroflex/Weinschel Model 44-20
(Quantity 2)
Tee Adapter Frequency: 10 MHz
Impedance: 50 Ohm
Connector: BNC(m) to BNC(f)/BNC(f)
Anritsu part number 3-2600-2
(Quantity 2)
Low Pass Filter 50 MHz Low Pass Filter Anritsu part number 1030-96
