Chapter 1 — General Information 1-6 Recommended Test Equipment
S412E MM PN: 10580-00324 Rev. N 1-5
Table 1-3. Recommended Test Equipment for Signal Generator Verification
Equipment Critical Specification
Recommended
Manufacturer/Model
RF Coaxial cable N(m) to N(m) connectors Anritsu 15NN50-1.5C
Frequency Counter 1 GHz frequency measurement Anritsu Model MF2412C
Table 1-4. Recommended Test Equipment for Option Verification
Equipment Critical Specification
Recommended
Manufacturer/Model
Load Test Fixture Resistance: 105 Ohm
Power: 1 Watt
Anritsu Model T3377
Load Test Fixture Resistance: 78 Ohm
Power: 20 Watts
Anritsu Model T3536
Calibration Tee N male Anritsu Model OSLN50-1
GPS Antenna Magnet Mount (active 3 V to 5 V) with
SMA connector
Anritsu p/n 2000-1528-R
Adapter Connector: SMA(m) to BNC(f) Pomona p/n 4290
Adapter Frequency: DC to 18 GHz
Connector: N(m) to N(m)
Anritsu Model 34NN50A
RF Coaxial Cable Frequency: DC to 18 GHz
Connector: N(m) to N(f), 50 Ohm
Anritsu p/n 15NN50-1.5C
Coaxial Cable Connector: BNC(m) to BNC(m) Anritsu p/n 2000-1627-R (Quantity 3)
Terminator Impedance: 93 Ohm
Connector: BNC(m)
Amphenol p/n
B1004A-ND3G-93R-0.05-1W
Vector Signal Generator Frequency: 100 kHz to 3 GHz Anritsu Model MG3700A with
options MG3700A-002 and
MG3700A-021.
Also requires LTE waveform license
MX370108A (for Option 541 or 542)
Power Meter Power Range: –70 dBm to +20 dBm Anritsu Model ML2438A
Power Sensor Frequency: 10 MHz to 18 GHz
Power Range: –60 dBm to +20 dBm
Anritsu Model MA2482D
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
Fixed Attenuator Frequency: DC to 18 GHz
Attenuation: 10 dB
Aeroflex/Weinschel Model 44-10
(Qty 2)
Frequency Reference 10 MHz Symmetricon Model,
RubiSource T&M
