1-8 Performance Verification Procedures Chapter 1 — General Information
1-8 PN: 10580-00324 Rev. N S412E MM
1-8 Performance Verification Procedures
Performance verification procedures are in the following Chapters:
• Chapter 2, “Vector Network Analyzer Verification”
• Chapter 3, “Spectrum Analyzer Verification”
• Chapter 4, “CW Signal Generator Verification”
• Chapter 5, “Option Verification”
Refer to Table 1-6 for the list of performance verification procedures required for the S412E. Perform all the
procedures with a “x” in the Std column. Also perform the procedures with an “x” in Option column when those
options are installed in the S412E. Options with a “N/A” in the Procedure Section are valid options for the
S412E, but do not require additional verification testing.
Table 1-6. Required Performance Verification Procedures for the S412E
Performance Verification Procedure Standard Options
Procedure
Section
VNA Frequency Accuracy x Section 2-2
VNA Transmission Dynamic Range x Section 2-3
VNA Return Loss Measurements Accuracy x Section 2-4
Spectrum Analyzer Frequency Accuracy x Section 3-2
Spectrum Analyzer Residual Spurious Response x Section 3-3
Spectrum Analyzer Displayed Average Noise Level (DANL) x Section 3-4
Spectrum Analyzer Single Side Band (SSB) Phase Noise x Section 3-5
Spectrum Analyzer Spurious Response (2nd Harmonic Distortion) x Section 3-6
Spectrum Analyzer Resolution Bandwidth Accuracy x Section 3-7
Spectrum Analyzer Amplitude Accuracy x Section 3-8
Spectrum Analyzer Third Order Intercept (TOI) x Section 3-9
Signal Generator Frequency Accuracy Verification x Section 4-2
VNA Mode Bias Tee Operational Check (Option 10) x Section 5-2
GPS Operational Check (Option 31) x Section 5-3
Fixed WiMAX Signal Analyzer (Option 46/47) x Section 5-4
Mobile WiMAX Signal Analyzer (Option 66/67) x Section 5-5
Modulation Fidelity Verification for P25/P25p2 (Option 521/522) x Section 5-6
Modulation Fidelity Verification for NXDN (Option 531/532) x Section 5-7
LTE Signal Analyzer Verification (Option 541/542) x Section 5-8
TETRA Analyzer and Coverage (Option 581/582) x Section 5-9
Modulation Fidelity Verification for DMR2 (Option 591/592) x Section 5-10
Signal Integrity Verification for PTC (Option 721/722) x Section 5-11
Vector Voltmeter (Option 15) x N/A
Interference Analysis (Option 25) x N/A
Channel Scanner (Option 27) x N/A
Mobile WiMax OTA Measurements (Option 37) x N/A
Coverage Mapping (Option 431) x N/A
EMF Measurements (Option 444) x N/A
AM/FM/PM Analyzer (Option 509) x N/A
LTE OTA Measurements (Option 546) x N/A
