Anritsu S412E - Test Records for Options Verification

Appendix A — Test Records A-5 Test Records for Options Verification
S412E MM PN: 10580-00324 Rev. N A-17
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
A-5 Test Records for Options Verification
GPS Verification, Option 31
Fixed WiMAX Signal Analyzer Verification, Options 46, 47
Table A-17. Option 31, Spectrum Analyzer Frequency Accuracy with GPS On
Frequency Specification Measured Value Deviation
1.5 GHz ± 75 Hz (± 50 ppb) GHz Hz
Table A-18. Option 46, Fixed WiMAX Channel Power Accuracy
Frequency Input Power
Measured Channel
Power (RSSI) Error Specification
2600.5 MHz –15 dBm dBm dB ± 1.5 dB
2600.5 MHz –50 dBm dBm dB ± 1.5 dB
3600.5 MHz –15 dBm dBm dB ± 1.5 dB
3600.5 MHz –50 dBm dBm dB ± 1.5 dB
5600.5 MHz –15 dBm dBm dB ± 1.5 dB
5600.5 MHz –50 dBm dBm dB ± 1.5 dB
Table A-19. Option 47, Fixed WiMAX Residual EVM
Frequency Power BW EVM (RMS) Specification
2600.5 MHz –15 dBm 10 MHz %
≤ 3.5%
2600.5 MHz –50 dBm 10 MHz %
≤ 3.5%
3600.5 MHz –15 dBm 10 MHz %
≤ 3.5%
3600.5 MHz –50 dBm 10 MHz %
≤ 3.5%
5600.5 MHz –15 dBm 10 MHz %
≤ 3.5%
5600.5 MHz –50 dBm 10 MHz %
≤ 3.5%
