A-5 Test Records for Options Verification Appendix A — Test Records
A-18 PN: 10580-00324 Rev. N S412E MM
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Mobile WiMAX Signal Analyzer Verification, Options 66, 67
Table A-20. Option 47, Fixed WiMAX Frequency Error
Frequency Power Frequency Error Specification
2600.5 MHz –50 dBm Hz
± 182.03 Hz
5600.5 MHz –50 dBm Hz
± 392.03 Hz
Table A-21. Option 66, Mobile WiMAX Channel Power Accuracy (10 MHz Bandwidth and 10 ms Frame Length)
Frequency
(MHz)
Input Power
(dBm)
Measured Channel Power
(RSSI) Error Specification
2600.5 –15 dBm dB ± 1.5 dB
2600.5 –50 dBm dB ± 1.5 dB
3600.5 –15 dBm dB ± 1.5 dB
3600.5 –50 dBm dB ± 1.5 dB
Table A-22. Option 66, Mobile WiMAX Channel Power Accuracy (5 MHz Bandwidth and 5 ms Frame Length)
Frequency
(MHz)
Input Power
(dBm)
Measured Channel Power
(RSSI) Error Specification
2600.5 –15 dBm dB ± 1.5 dB
2600.5 –50 dBm dB ± 1.5 dB
3600.5 –15 dBm dB ± 1.5 dB
3600.5 –50 dBm dB ± 1.5 dB
Table A-23. Option 67, Mobile WiMAX Residual EVM (10 MHz Bandwidth and 10 ms Frame Length)
Frequency
(MHz) Power (dBm) BW (MHz) EVM (RMS) Specification
2600.5 –15 10 % ≤ 3.0%
2600.5 –50 10 % ≤ 3.0%
3600.5 –15 10 % ≤ 3.0%
3600.5 –50 10 % ≤ 3.0%
