Appendix A — Test Records A-5 Test Records for Options Verification
S412E MM PN: 10580-00324 Rev. N A-19
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
P25/P25p2 Verification, Options 521, 522
Table A-27. Options 521 and 522, Signal Generator Modulation Fidelity Verification for P25
Table A-24. Option 67, Mobile WiMAX Frequency Error (10 MHz Bandwidth and 10 ms Frame Length)
Frequency
(MHz) Power (dBm) Freq Error Specification
2600.5 –50 Hz ± 52.01 Hz
3600.5 –50 Hz ± 72.01 Hz
Table A-25. Option 67, Mobile WiMAX Residual EVM (5 MHz Bandwidth and 5 ms Frame Length)
Frequency
(MHz) Power (dBm) BW (MHz) EVM (RMS) Specification
2600.5 –15 5 % ≤ 3.0%
2600.5 –50 5 % ≤ 3.0%
3600.5 –15 5 % ≤ 3.0%
3600.5 –50 5 % ≤ 3.0%
Table A-26. Option 67, Mobile WiMAX Frequency Error (5 MHz Bandwidth and 5 ms Frame Length)
Frequency
(MHz) Power (dBm) Freq Error Specification
2600.5 –50 Hz ± 52.01 Hz
3600.5 –50 Hz ± 72.01 Hz
Frequency Tx Pattern Mod Fid Specification
5.5 MHz
p25_1011 % < 1.25%
p25_511(O.153) % < 1.25%
845 MHz
p25_1011 % < 1.25%
p25_511(O.153) % < 1.25%
1545 MHz
p25_1011 % < 1.25%
p25_511(O.153) % < 1.25%
