A-5 Test Records for Options Verification Appendix A — Test Records
A-20 PN: 10580-00324 Rev. N S412E MM
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-28. Options 521 and 522, Signal Generator Modulation Fidelity Verification for P25p2 (Rev 2 Units Only),
NXDN Verification, Options 531, 532
Table A-29. Options 531 and 532, Signal Generator Modulation Fidelity Verification for NXDN
Frequency Tx Pattern Mod Fid Specification
5.5 MHz
p252_bs_1031 % < 2.00%
p252_bs_silence % < 2.00%
845 MHz
p252_bs_1031 % < 2.00%
p252_bs_silence % < 2.00%
1545 MHz
p252_bs_1031 % < 2.00%
p252_bs_silence % < 2.00%
Frequency Tx Pattern Mod Fid Specification
5.5 MHz
nxdn_1031_9600 % < 1.25%
nxdn_511(O.153)_9600 % < 1.25%
845 MHz
nxdn_1031_9600 % < 1.25%
nxdn_511(O.153)_9600 % < 1.25%
1545 MHz
nxdn_1031_9600 % < 1.25%
nxdn_511(O.153)_9600 % < 1.25%
