Chapter 1 — General Information 1-7 Replaceable Parts and Assemblies
S412E MM PN: 10580-00324 Rev. N 1-7
a. When ordering the Main/VNA PCB Assembly, in order to ensure installation of correct options, all options
that are installed on the instrument must be declared on the order. The options are listed and shown in the
System (Shift - 8) / Status display.
3-72767 Keypad Washer
3-905-2744 Keypad Screw
ND73192 Speaker
ND80480 Touchscreen with Protection
2000-1797-R Protective Film (Touchscreen not included)
806-141-R Automotive 12 Volt DC Adapter
3-2000-1498 USB Type 2 A to Mini B Cable, 3 meters (10 feet)
3-806-215 Signal Generator to Main PCB co-axial cable
783-1399 Signal Generator Cable Removal Tool
3-72758 Vent 1 (Fan Vent, above battery door)
3-72759 Vent 2 (Intake Vent, top vent on keypad side)
3-72760 Vent 3 (Battery Vent, bottom vent on keypad side)
3-72781 LCD Bracket, Units with serial numbers less than 1606078
3-76302 LCD Bracket, Units with serial numbers greater than 1606077
3-71625-1 Cable, LCD to Keypad, Units with serial numbers greater than 1329107 and less than 1606078
3-70675-1 Cable, LCD to Keypad, Units with serial numbers greater than 1606077
3-72771 Cable, Keypad to Main PCB, 15 cm
3-72770 Cable, Keypad to Inverter PCB, 6 cm, Units with serial numbers less than 1329107
3-72621-4 Cable, LCD to Main PCB, 7cm, Units with serial numbers less than 1606078
3-70674-4 Cable, LCD to Main PCB, 7cm, Units with serial numbers greater than 1606077
3-803-110 Cable, Ribbon, 2x20, Main to SPA PCB
3-806-197 Cable, MMCX-MMCX, DSP to SPA PCB
Table 1-5. List of Replaceable Parts and Assemblies (2 of 2)
Part Number Description
