A-5 Test Records for Options Verification Appendix A — Test Records
A-22 PN: 10580-00324 Rev. N S412E MM
S412E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
TETRA Verification, Options 581, 582
Table A-32. Options 581 and 582, Signal Generator EVM Verification for TETRA
DMR2 Verification, Options 591, 592
Table A-33. Options 591 and 592, Signal Generator Modulation Fidelity Verification for DMR2
PTC Verification, Options 721, 722
Table A-34. Units with Firmware Version 1.09 and Lower, Options 721 and 722, PTC Verification
Frequency Tx Pattern EVM Specification
5.5 MHz tetra_bs_idle_unallocPCH % < 3.5%
845 MHz tetra_bs_idle_unallocPCH % < 3.5%
1545 MHz tetra_bs_idle_unallocPCH % < 3.5%
Frequency Tx Pattern Mod Fid Specification
5.5 MHz
dmr2_bs_1031 % < 1.25%
dmr2_bs_511(O.153) % < 1.25%
845 MHz
dmr2_bs_1031 % < 1.25%
dmr2_bs_511(O.153) % < 1.25%
1545 MHz
dmr2_bs_1031 % < 1.25%
dmr2_bs_511(O.153) % < 1.25%
Frequency Symbol Rate Mod Fid Specification
5.5 MHz
6000 % < 1.75%
18000 % < 1.85%
845 MHz
6000 % < 1.75%
18000 % < 1.85%
1545 MHz
6000 % < 1.75%
18000 % < 1.85%
