Anritsu Site Master S331L Maintenance Manual

4-1 Replacing the S331L Batteries Assembly Replacement
4-2 PN: 10580-00323 Rev. B S331L MM
2. Remove the six screws screws from the bottom of the unit holding the battery cover in place, and remove
the battery cover.
3. Remove the battery connectors from the Main board by gently pulling on them and then remove the
batteries from the unit..
4. Inserting batteries is the reverse of removing them.
Figure 4-2. Battery Cover Removed
Figure 4-3. Unplug the Battery Connectors and Remove the Batteries
