Anritsu Site Master S331L Maintenance Manual

Assembly Replacement 4-2 Removing the Rear Case to Gain Access to Internal Assemblies
S331L MM PN: 10580-00323 Rev. B 4-3
4-2 Removing the Rear Case to Gain Access to Internal Assemblies
1. Remove the batteries as described in Section 4-1 “Replacing the S331L Batteries”
2. Remove the USB/Power cover assembly by removing the 4 screws.
3. Remove the RF Out mounting plate by removing the nut and washer holding the plate to the unit.
Figure 4-4. USB / Power Cover Removal
Figure 4-5. RF Out Mounting Plate Removed
