A-1 Test Records for Cable and Antenna Analyzer Verification
A-2 PN: 10580-00323 Rev. B S331L MM
A-1 Test Records for Cable and Antenna Analyzer Verification
S331L Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-1. Cable and Antenna Analyzer Frequency Accuracy
Frequency Measured Value Specification
1 GHz (1000 MHz) MHz 1 GHz ± 5 kHz (± 5 ppm)
3 GHz (3000 MHz) MHz 3 GHz ± 15 kHz (± 5 ppm)
Table A-2. Cable and Antenna Analyzer Return Loss Accuracy Verification
Offset Minimum Value Maximum Value Specification
Start Frequency = 2 MHz, Stop Frequency = 4 GHz
6 dB dB dB –4.3 dB x –7.7 dB
20 dB dB dB –17 dB x –23 dB
