ANSIMAG K+1516 - PART LIST 1: ANSI Pump Wet End Parts; Casing Options (150 LB & 300 LB); Encapsulated Drive and Impeller Assemblies

44
PARTS LIST 1
WET END PARTS ONLY – ANSI PUMPS Recommended Spare Parts for all levels of service.
PART NAME QTY K+1516 K+3156 K+326s K+326 K+436 K+1518 K+3158
1 Casing – 150 LB
1
ETFE lined K0107 P2847 P2846 K0108 K0109 K0110 K0111
CI PFA Lined K0107P N/A N/A N/A N/A N/A N/A
Stainless Steel, 316 K0107B N/A N/A K0108
B
K0109B K0110B K0111B
Hastelloy® B K0107E N/A N/A K0108
E
K0109E K0110E K0111E
Hastelloy® C K0107G N/A N/A K0108
G
K0109G K0110G K0111G
1
Casing – 300 LB
Stainless Steel, 316 K0107C N/A N/A K0108
C
K0109C K0110C K0111C
Hastelloy® B K0107F N/A N/A K0108F K0109F K0110F K0111F
Hastelloy® C K0107H N/A N/A K0108
H
K0109H K0110H K0111H
2 Fully Encapsulated Drive
– CFR/ETFE
1
A-drive, 10hp/3600, 5hp/1800 P2842AE P2843AE P2844AE K0211E K0214E
B-drive, 15hp/3600, 7.5hp/1800 P2842BE P2843BE P2844BE K0212E K0215E
C-drive, 30hp/3600, 15hp/1800 P2842CE P2843CE P2844CE K0213E K0216E
Impeller Assembly –
GFR/PFA
A-drive 10hp/3600, 5hp/1800 P2842D P2843D P2844D K0211P K0214P
B-drive 15hp/3600, 7.5hp/1800 P2842E P2843E P2844E K0212P K0215P
C-drive 30hp/3600, 15hp/1800 P2842F P2843F P2844F K0213P K0216P
2a Impeller Only (CFR /ETFE)
1 P4110 P4161 P4162 P4163 P4106
3 Containment Shell
1
CFR/ETFE w/CFR/Teflon® P2912A P2913A
GFR/PFA w/CFR/Teflon® P2912B P2913B
4
Inner Drive Only –
CFR/ETFE
A-drive 10hp/3600, 5hp/1800
B-drive 15hp/3600, 7.5hp/1800
C-drive 30hp/3600, 15hp/1800
1
P4172A
P4172B
P4172C
5 Mouth Ring Assembly
1
CFR-Teflon® K0501 K0503 K0505 K0501 K0510
SiC K0506 K0507 K0508 K0506 K0509
6 Pump Shaft –SiC
1 K0607
** 7 O-Ring, Mouth Ring
1 K0705 K0706 K0707 K0705 K0707
