ANSIMAG K+1516 - PART LIST 1: ANSI Pump Wet End Parts (Contd); Shaft Support;Thrust Rings and Rear Supports

45
PART LIST 1, continued
WET END PARTS ONLY - ANSI PUMPS
PART NAME QTY K+1516 K+3156 K+326s K+326 K+436 K+1518 K+3158
8 O-Ring, Casing
1
Viton® K0801 K0810
EPDM K0802 K0811
Teflon® coated Viton® K0803 K0812
Gore-Tex® wrapped
Teflon®/Viton®
P2343 P2344
Silicone K0804 Consult Factory
9 Main Bushing
1
CFR-ETFE, SiC (Ribbed,
Keyless)
CFR-ETFE, SiC
P4175
K0907
GFR-PFA, SiC K0907P
Carbon (Ribbed, Keyless)
Carbon
P4175A
K0908
11 Shaft Support/Thrust Ring
1
CFR-ETFE / SiC K1102 K1104 P2915A K1102 K1107
GFR-PFA / SiC K1102P K1104P P2915B K1102P K1107P
12 Rear Support
1
Ductile Iron K1201 P2363A
Stainless Steel K1206 P2363B
17 Lock Washer 1/2" (Rear
Support – Casing)
HL1/2
6 REQ
HL1/2
8 REQ
18 Hex bolts 1/2"-13 (Rear
Support – Casing)
HH1/2X1.50
6 REQ
HH1/2X1.75
8 REQ
* 61 Teflon Gasket (Drain)
1 K4903
* 62 Neoprene Gasket (Drain)
1 K4904
* 63 Drain Cover
1 K4902
64 Threaded Drain Cover (1/4”
NPT)
1 P2034
65 Drain Plug
1 P2035
* 66 Lock Washers ½” (Drain
Cover- Casing)
2 HL1/2
* 67 Hexbolts ½”- 13 (Drain Cover-
Casing)
2 HH1/2X1.25
Notes: 1. ANSI 300# flanges are available only on unlined 316 stainless steel or Hastelloy® pump cases.
* These items are included when ordering casings
** These items are included when ordering mouth rings
