ANSIMAG K+1516 - PART LIST 2: ANSI Pump NEMA Drive End Parts (Contd)

48
PART LIST 2
DRIVE END PARTS ONLY - ANSI PUMPS WITH NEMA MOTORS
PART NAME
Qty K+1516 K+3156 K+326s K+326 K+436 K+1518 K+3158
36 Hexbolt ½” – 13 (Bracket –
Bracket Riser, rear)
1 N/A HH1/2X1.75 N/A HH1/2X1.75
37 Lock Washers ½”
3
(Bracket
– Bracket Riser)
3 N/A HL1/2 N/A HL1/2
38 Flat Washer ½” ( Bracket –
Bracket Riser, rear)
1 N/A HW1/2 N/A HW1/2
39 Hexnut ½ (Bracket- Bracket
Foot, rear)
1 N/A HN1/2 N/A HN1/2
52 Hexbolt, Casing- Casing
Riser
56C & 143/145TC
182/184TC
213/215TC
254/256TC
284/286TSC
2
2
2
N/A
N/A
N/A
HH1/2X1.50
HH1/2X1.50
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
HH1/2X1.50
HH1/2X1.50
N/A
N/A
N/A
N/A
N/A
53 Hexnut, Casing- Casing Riser
56C & 143/145TC
182/184TC
213/215TC
254/256TC
284/286TSC
N/A
N/A
N/A
N/A
HN1/2
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
HN1/2
N/A
N/A
N/A
N/A
N/A
54 Lock Washer, Casing- Casing
Riser
56C & 143/145TC
182/184TC
213/215TC
254/256TC
284/286TSC
2
2
N/A
N/A
N/A
HL1/2
HL1/2
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
HL1/2
HL1/2
N/A
N/A
N/A
N/A
N/A
73 Bracket Plug, Drain
1 K3902 K3902 K3902 K3902
74 Bracket Plug, Setscrew
1 K3902 K3902 K3902 K3902
Notes:
1. With 28 frame mounting, all models require Item 15, P2536 bracket foot and hardware items 35,
36 and 38.
