PARTS LIST 3
DRIVE END PARTS ONLY - ANSI PUMPS WITH IEC MOTORS
PART NAME Qty K+1516 K+3156 K+326s K+326 K+436 K+1518 K+3158
14 Outer Drive
1
A-drive, IEC B5 80 frame RK1400 RK1400
A-drive, IEC B5 90 frame RK1401
A-drive, IEC B5 100/112
frame
RK1402
A-drive, IEC B5 132 frame RK1403
B-drive, IEC 80 frame P2236H
B-drive, IEC B5 90 frame RK1404
B-drive, IEC B5 100/112
frame
RK1405
B-drive, IEC B5 132 frame RK1406
B-drive, IEC B5 160 frame RK1407
C-drive, IEC B5 132 frame P2236V
C-drive, IEC B5 160 frame P2236U
14a Outer Magnet Ring
1
A – Drive P4091A
B – Drive P4091B
C – Drive P4091C
14b Adapter Hub
1
IEC B5 80 P4069N
IEC B5 90 P4069R
IEC B5 100/112 P4069S
IEC B5 132 P4069V
IEC B5 160 P4069K
14c Flat Head Counter sunk
2 02-414DJ
15 Bracket Foot - Close-Coupled
1
80, 90, 100/112 frame P1942 RK4507 P1942 RK4507
132 frame RK4507 RK4507 RK4507 RK4507
160 frame RK4507 RK4507 RK4507 RK4507
16 Lock Washers, ½” (Rear
Casing Support – Bracket)
4 HL1/2
19 Hex Bolts ½” (Rear Support
–Bracket)
4 HH1/2X1.5
20 Hex Bolts 304SS (Bracket –
Motor Mounting Plate)
4 HHM12X35
21 Motor Mounting Plate
1
80, 90 Frame RK3002
100/112 Frame RK3003
132 Frame RK3004
160 Frame RK3005
23 Lock Washers (Motor
Mounting Plate/Motor)
4
80, 90 frame HLM10
100/112 frame HLM12
132 frame HLM12
160 frame HLM16
To Next Page
