PART LIST 4
WET END PARTS ONLY – ISO PUMPS
Recommended Spare Parts for all levels of service
PART NAME - ISO Pumps QTY K+i32160 K+i50160 K+i65160 K+i32200 K+i40200
- JIS Pumps QTY K+j40160 K+j50160 K+j65160 K+j40200 K+j50200
1 Casing – ISO 2084, 16 Bar, ETFE
Lined Ductile Iron
1 RK0107 RK0108 RK0109 RK0110 RK0111
Casing – JIS 10KG/CM
2
, ETFE
Lined Ductile Iron
1 JK0107 JK0108 JK0109 JK0110 JK0111
2 Fully Encapsulated Drive –
CFR/ETFE
1
A-drive,
7.5 KW/3500, 3.75KW/1750,
5.5KW/2900, 3.0KW/1450
P2842AE P2843AE P2844AE K0211E K0214E
B-drive,
11KW/3500, 5.5KW/1750,
7.5KW/2900, 4.0KW/1450
P2842BE P2843BE P2844BE K0212E K0215E
C-drive,
22KW/3500, 11KW/1750,
18.5KW/2900, 9KW/1450
1
P2842CE P2843CE P2844CE K0213E K0216E
Impeller Assembly - GFR/PFA
1
A-drive,
7.5 KW/3500, 3.75KW/1750,
5.5KW/2900, 3.0KW/1450
P2842D P2843D P2844D K0211P K0214P
B-drive,
11KW/3500, 5.5KW/1750,
7.5KW/2900, 4.0KW/1450
P2842E P2843E P2844E K0212P K0215P
C-drive,
22KW/3500, 11KW/1750,
18.5KW/2900, 9KW/1450
1
P2842F P2843F P2844F K0213P K0216P
2a Impeller Only – CFR /ETFE
1 P4110 P4161 P4162 P4163 P4106
3 Containment Shell
1
CFR/ETFE w/CFR/Teflon P2912A P2913A
GFR/PFA w/CFR/Teflon P2912B P2913B
4 Inner Drive Only –
CFR/ETFE
A-drive,
7.5 KW/3500, 3.75KW/1750,
5.5KW/2900, 3.0KW/1450
B-drive,
11KW/3500, 5.5KW/1750,
7.5KW/2900, 4.0KW/1450
C-drive,
22KW/3500, 11KW/1750,
18.5KW/2900, 9KW/1450
1
1
P4172A
P4172B
P4172C
P4172A
P4172B
P4172C
5 Mouth Ring
1
CFR-Teflon K0501 K0503 K0505 K0501 K0510
SiC K0506 K0507 K0508 K0506 K0509
6 Pump Shaft – SiC
1 K0607
** 7 O-Ring (Mouth Ring)
1 K0705 K0706 K0707 K0705 K0707
8 O-Ring (Casing)
1
Viton® K0801 K0810
EPDM K0802 K0811
Teflon® Coated Viton® K0803 K0812
Gore-Tex® wrapped Teflon®
Viton®
P2343 P2344
Silicone K0804 Consult Factory
