ANSIMAG K+1516 - PART LIST 5: ISO Pump IEC Drive End Parts; IEC Brackets, Outer Drives, and Magnet Rings; IEC Motor Mounting Plates and Hardware

53
PARTS LIST 5
DRIVE END PARTS ONLY – ISO PUMPS WITH IEC MOTORS
PART NAME - ISO Pumps QTY K+i32160 K+i50160 K+i65160 K+i32200 K+i40200
- JIS Pumps QTY K+j40160 K+j50160 K+j65160 K+j40200 K+j50200
13 Bracket, Close-coupled, IEC
1 RK1302
14 Outer Drive
1
A-drive, IEC B5 80 frame RK1400
A-drive, IEC B5 90 frame RK1401
A-drive, IEC B5 100/112 frame RK1402
A-drive, IEC B5 132 frame RK1403
B-drive, IEC B5 90 frame RK1404
B-drive, IEC 80 frame P2236H
B-drive, IEC B5 100/112 frame RK1405
B-drive, IEC B5 132 frame RK1406
B-drive, IEC B5 160 frame RK1407
C-drive, IEC B5 132 frame P2236V
C-drive, IEC B5 160 frame P2236U
14a Outer Magnet Ring
1
A – Drive P4091A
B – Drive P4091B
C – Drive P4091C
14b Adapter Hub
1
IEC B5 80 P4069N
IEC B5 90 P4069R
IEC B5 100/112 P4069S
IEC B5 132 P4069V
IEC B5 160 P4069K
14c Flat Head Counter sunk
2 02-414DJ
15
Bracket Foot – Close Coupled
1
80, 90, 100/112 frame
P1942
RK4506
RK4506 RK4506
132 frame
RK4507
RK4507
RK4507 RK4507
160 frame
RK4507
RK4507
RK4507 RK4507
16 Lock Washers 12MM, Rear
Support/Bracket
4 HLM12
19 Hex Bolts ½” Rear
Support/Bracket
4 HHM12X30
20 Hex Bolts 304SS, Bracket Motor
Mounting Plate
HHM12X35
21 Motor Mounting Plate
1
80, 90 frame RK3002
100/112 frame RK3003
132 frame RK3004
160 frame RK3005
