ANSIMAG K+1516 - PART LIST 5: ISO Pump IEC Drive End Parts (Contd)

54
PARTS LIST 5 – continued
DRIVE END PARTS ONLY – ISO PUMPS WITH IEC MOTORS
PART NAME - ISO Pumps QTY K+i32160 K+i50160 K+i65160 K+i32200 K+i40200
- JIS Pumps QTY K+j40160 K+j50160 K+j65160 K+j40200 K+j50200
23 Lock Washers Motor Mounting
Plate/Motor
4
80, 90 frame HLM10
100/112 frame HLM12
132 frame HLM12
160 frame HLM16
24 Hex Bolts Motor Mounting
Plate/Motor
4
80, 90 frame HHM10X25
100/112 frame HHM12X25
132 frame HHM12X30
160 frame HHM16X40
25 Jack Screws M12
2 HHM12X40FT
26 Lock Washers M12, Bracket Motor
Mounting Plate
4 HLM12
33 Pump Casing Riser
1
80, 90, 100/112 frame
N/A
132 frame
RK5001 RK5003 RK5003 RK5003
160 frame
RK5001 RK5003 RK5003 RK5003
34 Foot Riser
80, 90, 100/112 frame
N/A
132, 160 frame
N/A
35 Hex Bolts M12 Bracket/Bracket
Foot
3
80, 90, 100/112 frame
HHM12X25 HHM12X40 HHM12X25 HHM12X40
132, 160 frame
HHM12X40 HHM12X40 HHM12X40 HHM12X40
37 Lock Washers M12
Bracket/Bracket Foot
3
HLM12
51 Name Plate, ATEX/CE
1
P4071
52 Hex Bolts ½” Casing – Casing
Riser
2
80, 90, 100/112 frame
N/A
132 frame
HHM12X35 HHM12X40
160 frame
HHM12X40
54 Lock Washers M12 – Casing –
Casing Riser)
2
HLM12
55 Earthing Kit, Grounding Lug
1
P4107
73 Bracket Plug, 3/8 NPT
1
K3902
