ANSIMAG K+1516 - Pump Component Specifications; Containment Shell and Magnetic Coupling; Close Coupled Bracket and Bearing Frame

59
CONTAINMENT SHELL
• Exceeds ANSI/ASME B73.3 Pressure and Temperature Ratings for Class 150 flanges.
• Injection molded carbon fiber filled ETFE fluoropolymer backed by non-metallic reinforcement.
• Integral carbon fiber filled PTFE back thrust ring standard, optional sintered silicon carbide.
• No energy losses due to eddy currents from magnetic coupling.
• Fully confined casing O-ring.
• Burst pressure, 1800 psi (124 bar) & 2000 psi (138 bar) for 6" and 8" models, respectively.
• Optional glass fiber filled PFA.
MAGNETIC COUPLING
• Neodymium Iron Boron for maximum torque.
• Designed for zero slippage and zero losses.
• Utilizes standard NEMA or IEC motors.
• Eliminates soft start devices.
• Ratings:
A-drive: 10 HP / 7.5 kW max @ 3500 rpm; 5 HP / 3.75 kW max @ 1750 rpm
A-drive: 5.5kW / 7.5 HP max @ 2900 rpm; 3.0 kW / 4 HP max @ 1450 rpm
B-drive: 15 HP / 11 kW max @ 3500 rpm; 7.5 HP / 5.5kW max @ 1750 rpm
B-drive: 7.5 kW / 10 HP max @ 2900 rpm; 4.0 kW / 5 HP max @ 1450 rpm
C-drive: 30 HP /22 kW max @ 3500 rpm; 15 HP / 11kW max @ 1750 rpm
C-drive: 18 kW / 24 HP max @ 2900 rpm; 9 kW /12 HP max @ 1450 rpm
Note: Limit max. temperature to 200
o
F (93
o
C) above 25 hp @ 3500 rpm
CLOSE COUPLED BRACKET
• Provides metal-to-metal fit to casing and motor.
• No alignment between motor flange and pump.
• Eliminates the flexible coupling and bearing frame.
• Drilled and tapped for leak monitoring sensor (3/8 NPT).
BEARING FRAME
• Group 1 ASME/ANSI B73.1-1991 dimensional.
• L
10
life of 30,000 hours.
• Large oil reservoir for cool operation and long oil life.
• Sight window for direct oil level indication.
• Sealed enclosure provides secondary containment (optional).
• Drilled and tapped for leak monitoring sensor (3/8 NPT).
