RECEIVER
Sensitivity Less than 1uV for 10dB(S+N)/N
Image Rejection 70dB
Adjacent Channel Rejection 60dB
IF Frequencies
1st 10.695MHz
2nd 455KHz
Automatic Gain Control(AGC)
Less than 10dB change in audio
Output for inputs from 10 to 50000uV
Squelch less than 1uV
Audio Output Power 1Watts
Frequency Response 300-3000Hz
TRANSMITTER
Power Output 4 WattsFM/AM
Transmission interference inferior to 4nW(-54dBm)
Frequency Response 300-3000Hz
Modulated signal distortion inferior to 5%
Output Impedance 50 ohms
SPECIFICATION
GENERAL
Modulation Mode AM/FM
Frequency Range 26.565-27.99125MHz
Frequency Tolerance 0.005%
Input Voltage 13.2V
Dimensions(in mm)
104x108x25cm
Weight 416g
Ferquency Control PLL Synthesizer
Operating Temperature
Range
-20
℃
to +50
℃
Current Drain
Transmit with push-to-talk /UP/DN and coiled cord
Receive 2A MAX
VOL Max Squelched 0.3A
Weight 0.8A
Antenna Connector UHF,SO-239
