Adjusting

Hotkeys

1 Source/Auto/Exit

2 Clear Vision/<

3 Volume/Image ratio/>

4 Menu/Enter

5 Power

Menu/Enter

When there is no OSD, Press to display the OSD or conrm the selection.

Power

Press the Power button to turn on the monitor.

Volume/Image ratio

When there is no OSD, Press > Volume button to active volume adjustment bar, Press < or > to adjust volume.

When there is no OSD, Press > hotkey to active image ratio , Press < or > to adjust 4:3 or wide. (If the product screen

size is 4:3 or input signal resolution is wide format, the hot key is disable to adjust).

Source/Auto/Exit

When the OSD is closed, press Source/Auto/Exit button will be Source hot key function.

When the OSD is closed, press Source/Auto/Exit button continuously about 2 second to do auto congure (Only for the

models with D-Sub).

Questions and Answers:

Need help?

Do you have a question about the AOC 27B1H2 and is the answer not in the manual?

AOC 27B1H2 Specifications

General

Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat
Response time	9 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
NTSC coverage (typical)	82 %
Viewable size, vertical	336.31 mm
sRGB coverage (typical)	100 %
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	597.88 mm
Display brightness (typical)	250 cd/m²
HDMI	Yes
HDMI version	1.4
Headphone out	-
Input current	1.9 A
Power consumption (standby)	- W
Power consumption (typical)	23 W
Tilt angle range	-4 - 21.5 °
Product color	Black
Compatibility	BSMI / KC / KCC / e-Standby / RCM / MEPS / CE / FCC
