AOC 27B1H2 User Manual

1
Safety
National Conventions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These
blocks are notes, cautions, and warnings, and they are used as follows:
NOTE:
A NOTE indicates important information that helps you make better use of your computer system.
CAUTION:
A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING:
A WARNING indicates the potential for bodily harm and tells you how to avoid the problem. Some warnings
may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specic presentation of the
warning is mandated by regulatory authority.

AOC 27B1H2 Specifications

General

Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat
Response time	9 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
NTSC coverage (typical)	82 %
Viewable size, vertical	336.31 mm
sRGB coverage (typical)	100 %
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	597.88 mm
Display brightness (typical)	250 cd/m²
HDMI	Yes
HDMI version	1.4
Headphone out	-
Input current	1.9 A
Power consumption (standby)	- W
Power consumption (typical)	23 W
Tilt angle range	-4 - 21.5 °
Product color	Black
Compatibility	BSMI / KC / KCC / e-Standby / RCM / MEPS / CE / FCC

Weight and Dimensions

Depth (with stand)	199.8 mm
Width (with stand)	613.1 mm
Height (with stand)	460.1 mm
Weight (with stand)	3200 g
