Service Manual AOC 931SW+
12
3.5 LCD module input terminal pin assignment
Pin No Symbol Function Pin No Symbol Function
1 RXO0- LVDS input odd 16 RXE1- LVDS input even
2 RXO0+ LVDS input odd 17 GND GND Ground
3 RXO1- LVDS input odd 18 RXE2- LVDS input even
4 RXO1+ LVDS input odd 19 RXE2- LVDS input even
5 RXO2- LVDS input odd 20 CLKE- Clock signal -even
6 RXO2+ LVDS input odd 21 CLKE+ Clock signal +even
7 GND GND Ground 22 RXE3- LVDS input even
8 CLKO- Clock signal -odd 23 RXE3- LVDS input even
9 CLKO+ Clock signal +odd 24 GND GND Ground
10 RXO3- LVDS input odd 25 NC No connection
11 RXO3+ LVDS input odd 26 NC Test pin(Can’t to GND)
12 RXE0- LVDS input even 27 NC No connection
13 RXE0+ LVDS input even 28 VCC 5V power supply
14 GND GND Ground 29 VCC 5V power supply
15 RXE1- LVDS input even 30 VCC 5V power supply
To Next Page
