Service Manual AOC 931SW+
41
9.BOM List
9.1 Model：T9ANR5NYNNACNNJ
Note: The parts information listed below are for reference only, and are subject to change
Location Part number Description Remark
040G 58160811A GREEN DOT LABEL 1
040G 581689 4A BARCODE LABEL FOR 1 1
052G 1207 A ALUMINIUM TAPE 2
052G 1211 B
Conductive Tape 85mm *40mm *0.09mm (单导)
2
E08902 089G 725CAADBD D-SUB CABLE 1500MM
2nd source
E08902 089G 725GAADBD D-SUB CABLE 1500MM
2nd source
E08902 089G 725LAADBD D-SUB CABLE 1500MM 1
E08907 089G179J30N 9 FFC CABLE 1
E08907 089G179W30N 9 FFC CABLE
2nd source
E08901 089G414A15N HL POWER CORD 1500MM China Reg 1
E08901 089G414A15N IS POWER CORD 1500MM China Reg
2nd source
E08901 089G414A15N YH AC POWER CORD 1500MM CHINA Reg.
2nd source
0M1G1030 6120 SCREW 3x6 5
0M1G1740 10 47 CR3 SCREW 4x10 3
0M1G1740 10120 SCREW 3
0M1G3030 5120 SCREW 4
E750 750GLD1905TB11N000 LCD TMS190WX1-05TB A SH TMS
2nd source
E750 750GLD1905TB31N000 LCD TMS190WX1-05TB C SH TMS
2nd source
E750 750GLD1905TB61N000 PANEL TMS190WX1-05TB P SH TNMA 1
E750 750GLV1908CA21N000 TPM190A1-WX108TC P1 FQ TPV
2nd source
E750 750GLV1908CC14N000 PANEL TPM190A1-WX108TC C1 FZ TPV
2nd source
E750 750GLV1908CP14N000 PANEL TPM190A1-WX108TC P1 FZ TPV
2nd source
756GJACB AA015 MCU ASS'Y CBPCAR5ACJ1 mainboard G3244-2
0
U402 056G1133137 IC MX25L2026MI-12G SOP-8
2nd source
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8
2nd source
SMTCR-U402 100GARV9001B11 AOC931SW+_RTD2270_TPM190A1_100611_V001
0
CBPCAR5ACJ1 mainboard G3244-2-2-X-3-100609 1
CN408 033G3802 6B Y CONN 6PIN 2.0
2nd source
CN408 033G3802 6B Y L WAFER 1
CN404 033G3802 9B Y CONNECTOR 9P 2.0
2nd source
CN404 033G3802 9B Y L CONN 2.0 9P 1
CN403 033G801930F CH L FFC CONN 1.0mm 30P R/A 34mm 6mm 1
CN403 033G801930F CH JS FFC CONN 1.0mm 30P R/A 34mm 6.3mm 0
040G 45762412B CBPC LABEL 1
R480 061G152M229 64 2.2 OHM 2W 5% MOF 1
CN101 088G 35315F HD D-SUB CONN 15P BLUE - R/A 1
X401 093G 22 53 J CRYSTAL 14.31818MHZ/32PF49US 0
X401 093G 22 53 YC Crystal 14.31818MHz/32PF 49U/S YC 1
AIGAR5A1J1 MAIN BOARD FOR AI 1
C427 067G 3051014PT CD263 EC 100UF 20% 25V 6.3*11 1
C423 067G 3051014PT CD263 EC 100UF 20% 25V 6.3*11 1
C421 067G 3051014PT CD263 EC 100UF 20% 25V 6.3*11 1
SMTCAR5A1J1 MAIN BOARD FOR SMT 1
040G 45762420A LABEL 25x6mm 1
U401 056G 562266 IC Scaler RTD2270S-GR LQFP-64 1
U404 056G 563 52 LDO AP1117D33G-13-77 1
