AOC 931SW series - 1 LCD Specifications; Product Features

Service Manual AOC 931SW+
4
1. LCD Specifications
1.1 Product Features
Monitor Model AOC 931SW+
LCD Panel
Driving system TFT Color LCD
Active Display Area
481mm（19inch） diagpnal
408.24mm (W)×255.15mm(H)
Pixel Pitch 0.2835 mm×0.2835mm
Input
Video
R,G,B Analog Interface，75ohm,0.7V
Positive
Separate Sync. H/V TTL
H-Frequency 30kHz—83kHz
V-Frequency 55Hz--75Hz
Input Connector
D-Sub 15pin
Display Colors 16.7M Colors
Dot Clock 135MHz
Max. Resolution 1440 x 900@75Hz
Plug & Play VESA DDC2B DDC/CI
Power Consumption
ON Mode <37W
Power Saving Mode <1W
Switch OFF
<1W
Power Source
90~264VAC,47~63Hz, 1.5A Max supply current
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity : 5% to 80%
Dimensions(including stand)
439(W)x210(H)x358(D)mm
Weight (N. W.): 3.8kg
Safety
CCC
