AOC 931SW series User Manual

Service Manual AOC 931SW+
9
User
Red Red Gain from Digital-register
Green Green Gain Digital-register.
Blue Blue Gain from Digital-register
Color Boost
Full Enhance on or off Disable or Enable Full Enhance Mode
Nature Skin on or off Disable or Enable Nature Skin Mode
Green Field on or off Disable or Enable Green Field Mode
Sky-blue on or off Disable or Enable Sky-blue Mode
A
utoDetect on or off Disable or Enable AutoDetect Mode
Demo on or off Disable or Enable Demo
Picture Boost
Frame Size 14-100
A
djust Frame Size
Brightness 0-100
A
djust Frame Brightness
Contrast 0-100
A
djust Frame Contrast
H. position 0-100
A
djust Frame horizontal Position
V.position 0-100
A
djust Frame vertical Position
Bright Frame on or off Disable or Enable Bright Frame
OSD Setup
H.Position 0-100
A
djust the horizontal position of OSD
V.Position 0-100
A
djust the vertical position of OSD
Timeout 5-120
A
djust the OSD Timeout
Transparence 0-100
A
djust the transparence of OSD
Language Select the OSD language
Extra
Input Select D-Sub Select Analog Sigal Source as Input
A
uto Config yes or no
A
uto adjust the picture to default
Image Ratio wide or 4:3 Select wide or 4:3 format for display
DDC/CI yes or no Turn ON/OFF DDC/CI Support
Information
Show the information of the main
image and sub-image source
Reset
Reset yes or no Reset the menu to default
Exit
Exit Exit the main OSD
2.3 OSD Lock Function
Press “menu” and hold,with turn on “Power”, the OSD menu is locked. Again, the OSD menu is non-locked.
For the OSD menu function ,Please refer to “user manual” .
