AOC 931SW series User Manual

Service Manual AOC 931SW+
15
4.4 Software Flow Chart
------Just for your reference.
Start
Initial_MCU
Check if DataBuffer Is blank
&Chec
k
if Sum is chan
g
ed ?
To Write default values
Read parameter_from Buffer
PowerHandler
Init_GlobalVariables
Initial_MCU Device
while
InputTiming
ModeHandler
MenuHandler
DebugHandler
if standby mode?
Brightness
Contrast
Language
InputType
InputTimingStableCounter
OsdCounter
PowerDownCounter
LED turn-on
Show power on logo
if factory mode?
No signal message
UnsupportModeFlag
END
OSD Menu
Software Flow Chart
InputTiming
Phaes/Frequency
Image setup
Color
Options
Enter factory mode OSD

AOC 931SW series Specifications

General

Brand	AOC
Model	931SW series
Category	Monitor
Language	English
