6. USB upstream 7.
USB3.2 Gen1 downstream + fast charge x1
2. HDMI 1
Cable connections on the back of the monitor:
USB3.2 Gen1 downstream x1 8.
Headphone jack
To protect the monitor, always turn off the monitor and computer before connecting.
3. HDMI 2
11
Connecting to a
computer: 1. Turn off the computer and unplug the power
cord. 2. Connect the signal cable to the video input connector on the back of the monitor and the video output connector of the
computer graphics card. 3. Connect the display signal cable to the video
connector on the computer. 4. Plug the monitor and computer power cords into
nearby electrical outlets. 5. Turn on the monitor and computer.
4. DP1
If the monitor displays an image, the installation is complete. If the monitor does not display an image, refer to Troubleshooting.
5. DP2
1. Power supply
1
5
2
4
6 8
7
3
connect monitor
