6. Block Diagram
6.1 LCD Block Diagram
The LCD Monitor will contain main board, power board, key board which house the flat panel control logic,
brightness control logic and DDC.
The power board will provide AC to DC main board chips each voltage. and the Inverter voltage DC to AC to drive
the backlight of panel
6.2 Main Board Block Diagram
DC-AC inverter
AC-DC (5V/12V)
Power Board
Main Board
Key board
D- SUB
/DDC
Backlight 4-CCFL
Panel
LVDS
AC supply
90V-264V
Monitor Block Diagram
PC- DVI
/DDC
Input signal
HDMI
/DDC
Audio
Amplifiers
Audio in
Earphone
Speaker
3W×2
DP
/DDC
Crystal 14.318MHZ
(X401)
Panel Interface
Scalar
MST8757T LFBGA-355
(U401)
D-Sub
(U1)
FLASH
MX25L1606EM2I-12G
(U402)
HDMI
Key Board
Control
Voltage converter
5V
5V 3.3V 1.8V
DVI
(U1)
Main Board Block Diagram
DP
