AOC G2460PQU Service Manual

Service Manual G2460PQU
4
1. Monitor Specifications
1.1 Product Features
Panel
Model number
G2460PQU
Driving system
TFT Color LCD
Viewable Image Size
61.0 cm diagonal
Pixel pitch
0.27675 mm(H) x 0.27675 mm(V)
Video
R, G, B Analog Interface & Digital Interface &
HDMI Interface & DP Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
165 MHz (DVI:300MHz)
Resolution
Horizontal scan range
30 kHz – 83 kHz(30 kHz ~ 140 kHz)
Horizontal scan Size
(Maximum)
531.36 mm
Vertical scan range
50 Hz - 76 Hz (50 kHz ~ 120 kHz)
Vertical scan Size(Maximum)
298.89 mm
Optimal preset resolution
1920 x 1080 (60 Hz)
Plug & Play
VESA DDC2B/CI
Input Connector
VGA / Dual link DVI / HDMI / DP
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source
100-240V~, 50/60Hz
Power Consumption
Active 42 W (typical)
Standby < 0.5 W
Off timer
0～24 hrs
Speakers
2W x 2
Physical
Characteristics
Connector Type
VGA \ DVI \ HDMI \ DP \ Line in \ Earphone out
Signal Cable Type
Detachable
Dimensions & Weight
Height(with base)
393.6 mm~523.6 mm
Width
565.4 mm
Depth
243.5 mm
Weight(monitor only)
6.16 kg
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25° to 55°
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating
0~12192m (0~ 40000 ft )

AOC G2460PQU Specifications

General

3D	No
Panel type	TN
Color depth	6 bit
Pixel pitch	0.276 x 0.276 mm
Aspect ratio	16:9
Product type	PC monitor
Backlight type	W-LED
Pixel frequency	330 MHz
Display diagonal	23.6 \
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	298.89 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	531.36 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
AC adapter included	Yes
Mean time between failures (MTBF)	50000 h
HDMI version	1.4
USB hub version	2.0
DisplayPort version	1.1
Component video (YPbPr/YCbCr) in	0
USB Type-A downstream ports quantity	4
Tilt angle range	-5 - 22 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Thin client installed	-
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.22 W
Power consumption (standby)	0.31 W
Power consumption (typical)	22.7 W
Certification	ISO
Product color	Black
Market positioning	Gaming
Package weight	8550 g
Cables included	Audio (3.5mm), DVI, USB, VGA
Doesn't contain	BRF, PVC
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (without stand)	52.95 mm
Width (without stand)	565.4 mm
Height (without stand)	342.9 mm
Weight (without stand)	6540 g
