AP Diving AP50 - EV50 Auto Air Hose Assembly (New Model with Standard Hose)

AP Diving Ltd. Medium Pressure and Convoluted Hose Shortening Instructions
Page 7 of 38
2.2 EV50 Auto Air Hose Assembly (new model with standard hose)
NUMBER
DESCRIPTION
PART NUMBER
QUANTITY
1
O-ring
BS-903-N70
1
2
3/8” UNF end
AP-50-P4
1
3
Hose collar
AP-50-P3
2
4
LP hose
AP-50-C
1
5
Coupling body
RB-70-30
1
6
Blue moulded washer
AP-150-18
1
7
Spring
AP-150-11
1
8
Sliding collar
AP-150-12
1
9
O-ring
BS-5.6x2.4-N70
1
10
Funnel seat
AP-150-05
1
11
Spring
AP-150-08
1
12
Valve float
AP-150-6B
1
13
O-ring
BS-109-N70
1
14
Guide washer
AP-150-10
1
15
Valve sleeve
AP-150-14
1
16
Ball bearing
AP-150-13
4
This hose is used on:
- All AP Evolution and Inspiration EVO rebreathers since 2005,
- All AP Evolution Plus and Inspiration EVP rebreathers,
- All AP Inspiration and Inspiration XPD rebreathers since 2008, and
- All AP BCD’s and wings fitted with an Auto Air since February 2009.
