AP Diving AP50 - AP150 Auto Air Hose Assembly (Old Model with Bigger Bore Hose)

AP Diving Ltd. Medium Pressure and Convoluted Hose Shortening Instructions
Page 8 of 38
2.3 AP150 Auto Air Hose Assembly (old model with bigger bore hose)
NUMBER
DESCRIPTION
PART NUMBER
QUANTITY
1
O-ring
BS-903-N70
1
2
3/8” UNF end
AP-150-01
1
3
Hose collar
AP-150-02
2
4
LP hose
AP-150-C
1
5
Coupling body
AP-150-04
1
6
Blue moulded washer
AP-150-18
1
7
Spring
AP-150-11
1
8
Sliding collar
AP-150-12
1
9
O-ring
BS-5.6x2.4-N70
1
10
Funnel seat
AP-150-05
1
11
Spring
AP-150-08
1
12
Valve float
AP-150-6B
1
13
O-ring
BS-109-N70
1
14
Guide washer
AP-150-10
1
15
Valve sleeve
AP-150-14
1
16
Ball bearing
AP-150-13
4
This hose was used on:
- All AP Evolution rebreathers until 2005,
- All AP Inspiration rebreathers until 2008, and
- All AP BCD’s and wings fitted with an Auto Air until February 2009.
