Smart-UPS XL 3U Rack Mount 2200/3000 VA 120/230 Vac; 3000 VA 100/200 Vac User Manual 5
Installation
Installation
Your UPS model may vary in appearance from the examples depicted in this manual.
Install the Rails in the Rack
This UPS is intended for installation in a 19” rack.
For details on rail installation refer to the instructions in the rail kit.
Install the UPS in the Rack and Connect the Battery Module
Install the UPS at or near the bottom of the rack.
The UPS and the battery modules are heavy. Remove the battery modules to lighten the UPS
during installation.
4x
4x
!
"
#
$
%
&
To Next Page
