Symmetra PX 10-80 kW 208 V Installation Sheet
Single Mains Installation
Remove labels on Bypass Input by pushing up the nylon tap. Remove
brackets on the L1, L2, L3 Mains Input and on L1, L2, L3 Bypass
Input. Save brackets for later conversion to dual mains if applicable.
Attach the 3 copper brackets L1, L2, and L3 (shipped in plastic bag in
the cable-land area of the UPS), using provided bolts and nuts.
Connect the cables to the AC mains input busbars, using provided
bolts and nuts.
Proceed with ground connections. Feed ground wire through provided
ferrite beads.
Route input and output wires in separate conduits: For output cables
L1, L2, L3 & N, use A and B conduits. For L1, L2, L3 & N mains
input, use conduits C and E.
Feed DC cables through the chase nipple in left side of the UPS and
into the Battery Enclosure.
B
E
A
C
L
1
L
2
L
3
L
1
L
2
N
N
L
3
UPS
Battery Enclosure
3
EPO Switch Wiring
The UPS is to be connected to either a dry contact or a 24Vdc Emergency
Power Off (EPO) switch.
The EPO circuit is considered Class 2 and SELV (Safety Extra Low
Voltage). A SELV circuit is isolated from primary circuitry through an
isolating transformer and designed so that under normal conditions, the
voltage is limited to 42.4Vac peak or 60Vdc. SELV and Class 2 circuits
must be isolated from all primary circuitry. Do not connect any circuit to
the EPO terminal block unless it can be confirmed that the circuit is SELV
or Class 2.
For installations in US
– CL2Class 2 cable for general purpose use.
– CL2PPlenum cable for use in a vertical shaft or from floor to
floor.
– CL2R Racer cable for use in dwellings and raceways.
– CL2XLimited use cable for dwellings and raceways.
For installations in Canada
– CL2RCertified, type ELC (Extra-Low-Voltage Control Cable).
– CL2XCertified, type ELC (Extra-Low-Voltage Control Cable).
L1L2 L3 N
G
G
14 1412 1211 1199887766554433221 1
4321
L1L2L3 N
8765 8765
XX XX
4321 4321
8765
L1L2 L3 N
10 1013 13
(NO = normally open)
(NC = normally closed)
EPO Wiring Options
DC Input
AC
Input
AC
Output
EPO / Ancillary
Maintenance
Bypass Interface
1. Dry NO
Contacts
2. +24V NO
(remove jumper)
3. Dry NC
Contacts
(remove jumper)
4. +24V NC
(remove jumper)
Mains Input
Power
Output
Power
EPO
Switch
Batt +
Batt. –
Batt. CT
Bypass
Input
Power
Single Mains / Dual Mains
Dual Mains
UPS
Symmetra PX 10-80 kW 208 V Installation Sheet
4
Communication cables
Side panel removal
Remove right terminator from Port 2. Save for reinstallation in Battery
Enclosure. Connect Battery Communication cable to port 2.
Connect Network Communication Cable to Network Port as required.
Unlock right-side panel using key.
Depress latches.
Pull out panel and lift it off the UPS.
Route cables through front holes of UPS. Exit UPS from bottom or top
Warning
WARNING!
Ensure Total Power OFF before removing side panel (see
Total power OFF procedure).
Use 5-m standard Cat 5 Data cable (supplied). If cable length
is inadequate, a longer Cat 5 cable, or couplers, can be used
(not supplied). Maximum length of standard CAT 5 data
cable: 50 m.
IN
T
E
L
L
I
G
E
N
C
E
M
O
D
U
L
E
I
N
T
E
L
L
IG
E
N
C
E
M
O
D
U
L
E
S
ym
me
t
r
a
¤
PX
1
0
-
40
k
W
,
20
0
V
B
as
i
c
O
p
e
ra
ti
o
n
G
u
id
e
DOCUMENT STORAGE
?
XR Communications
Switch Gear Monitor Card
Port 1
Port 2
Display / Computer Interface
Display
Remote
Power View
Computer
Interface
Reset
Link
-RX
/T
X
10
/100
Status
10/100Base-T
AP9617 Network Management
To Next Page
