APC Symmetra PX Site Preparation Guide

Contents
Symmetra PX 10-40 kW 208 V Site Preparation Guide - 990-4060B i
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . 1
SAVE THESE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Symbols used in this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview of System Components . . . . . . . . . . . . . . . . . . . . . . . 2
Optional equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Space considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Electrical Information . . . . . . . . . . . . . . . . . . . . . . . . . . 4
EPO Switch wiring (required) . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Basic Wiring Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Site Preparation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

APC Symmetra PX Specifications

General

Noise level	61 dB
Output power	32000 W
Output power capacity	32 kVA
Emergency Power Off (EPO)	Yes
Battery type	VRLA
Dimensions (WxDxH)	1200 x 1070 x 1991 mm
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	3.5 h
Certification	EN 50091-1, EN/IEC 62040-3, EN/IEC 62040-1-1, FCC Part 15 Class A, VFI-SS-111
Product color	Black
Operating altitude	0 - 999.9 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	-15 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	1095400 g
Package weight	1189000 g
