Mount the IMU rigidly so that it cannot move or rotate
independently of the vessel.
Install the IMU where the data and power cable will reach easily
between the IMU and the PCS.
Ensure there is sufficient clearance for the connectors at both
ends of the data and power cable. Tighten the connectors by
hand only.
Mount the IMU so that it is approximately level.
Do not immerse the IMU in water or any liquid.
Respect the environmental limits listed for the
Inertial
Measurement Unit on page
2-5 for storage and operation.
Refer to the
Drawings section on page E-1 for dimensional
details to help when you install the IMU.
Connect the IMU housing to a good ground connection.
b) PCS Positioning:
Protect the PCS from shock, vibration and moisture.
Allow easy access to the front and the rear panels of the PCS.
Refer to the
Drawings section on page E-1 for dimensional
details to help when you install the PCS.
Connect the primary GNSS antenna to the ANT1 port.
Connect the secondary GNSS antenna to the ANT2 port
If necessary, connect the Differential GNSS corrections to a
COM port.
Connect the IMU data and power cable to the IMU port.
(POS MV V4) Connect an electrical supply of nominal voltage
110 Vac at 1.0 A; 240 Vac at 0.25 A, 47 to 63 Hz (voltage range -
90 Vac to 264 Vac) to the 3-pin IEC mains inlet connector on the
PCS. The PCS uses an auto-switching power supply that
configures itself to the applied ac electrical supply.
