Attach Legs to Rails
Tools ½ - inch Box End Wrench Hardware Required:
Required: ½ - inch Socket Wrench
Parts 2 Rails
Required: 2 Leg Ends
Install the Rear Rail to the Table Legs
1. Images below show adding the rear rail to the right leg first, based on the orientation described above. However,
you could start with the left leg if it is more convenient, but keep in mind of the photo orientation.
1. The flat rail side faces the leg’s center. Lift the rail end
on to the leg’s rear mounting bracket. Tilt the leg
toward the rail so that the rail is flush with the
mounting bracket on the leg.
2. Insert two bolts (B) through the
rail and leg mounting bracket.
Add lock washers (C) and nut (D).
HAND TIGHTEN FOR NOW.
