Standard Table - Step 4: Install the Roller End Arms
Tools Required: ½ - inch Open-End Wrench
or Crescent Wrench
½ - inch Socket Wrench
1. Note the different placement for the End Arm Mounting Holes for the Lucey versus the Lenni.
2. Above is shown on Lucey as Lenni’s Roller End Arm would be in the back two
holes. Install the bolt, washer and nut as shown.
Standard table legs are universally built for both Lenni
and Lucey machines. The end arm’s long nose will point
toward the NEEDLE end of the quilting machine.
Use the mounting holes as shown below that match your
machine type.
