Motor Brushes
Check the motor brushes about once a year.
Tools needed: APQS Parts:
#2 Phillips Screwdriver Motor Brush set – 3106-01 (US & Canada)
Flat Blade Screwdriver Motor Brush set – 3106-02 (CE – 220v motors)
Paper Towels
Air Compressor or Canned Air
Vacuum
Time to complete: Approximately 10 minutes
IMPORTANT: Disconnect power to the machine before proceeding!
Accessing Motor Brushes
Remove 5 screws on each side of machine as shown below. Lift off the top cover. (The procedure is the same
for Millie and Freddie machines.
Use a straight blade screwdriver to remove the brush caps on both sides of the motor.
Removing Motor Brush Caps
Remove 5 screws on
each side of cover
Lift motor cover
off machine to expose
motor
