Hopping Foot Height Adjustment
Tools needed:
Business Card (standard card stock – not plastic coated)
Flat Blade Screwdriver with long handle – 3/16” wide shaft, 3/16” wide tip – also known as ‘Cabinet Tip’
Flash light
Time to complete:
Approximately 5 minutes
To access the hopping foot clamp, remove the black plastic cap on the right side of the machine near the
tension control unit.
Use a flash light to locate the hopping foot clamp screw. This screw will be easily accessible when the
hopping foot is at its LOWEST position only.
Hopping foot clamping screw
Use flashlight to see clamping screw
Adjustment screw access cover
