Rotating the cam nut makes the wheel move closer or farther away from the rail. Note the reference mark on the cam
nut shown below.
When the reference mark points directly away from the table rail, the wheels are as loose as possible (Step 2). As you
turn the cam nut and move the reference mark closer to the rail, the wheel gets tighter. When the mark points directly at
the rail, the wheel is as tight as possible (Step 4).
NOTE: Always set the left and right wheel cams to the same position.
1. The front wheel grooves fit over the front rail lip as
shown above. These front wheels are adjustable for a
custom table fit and feel. The “offset cam nut” holds
each wheel to the axle.
2. Wheel is as loose as
possible.
3. Wheel is set to medium grip
on the rail.
4. Wheel is as tight as possible.
