Cord Management (Bliss or Non-Bliss)
1. Plug the power cord into
the machine.
2. Feed the power cord into the plastic cord supports.
3. Use the two Velcro strips attached to
the right handle to support the power
cord and CAT-5 Carriage Encoder
Cable.
4. Slip the cushion clamp over the power cord. Insert
the mounting screw into the mounting hole. Just
get it started for now.
5. Push the machine all the way forward to check the cord travel. Adjust the cushion clamp on the
carriage to allow free movement without binding the cords or having them rub on the table.
Tighten the cushion clamp. Use zip ties to hold the carriage encoder cable and main power cable
together. Trim zip tie ends.
