Parameters Range
x: day of the week code [0 – 9]
0: Monday
1: Tuesday
2: Wednesday
3: Thursday
4: Friday
5: Saturday
6: Sunday
7: Weekdays
8: Weekends
9: Everyday
y: event code
4-events per day configuration [0 – 3]
0: Wake
1: Leave
2: Return
3: Sleep
2-events per day configuration [0 – 1]
0: Wake/Occupied
1: Sleep/Unoccupied
hh: event start time hours in 24-hour format [00 – 23]
mm: event start time minutes [00 – 59]
HT: event heat setpoint
Fahrenheit [40 – 90]
Celsius [4 – 32]
CL: event cool setpoint
Fahrenheit [42 – 99]
Celsius [6 – 37]
fan: event programmed fan mode [AUTO, A, ON, CIRC]
AUTO, A: fan auto mode
ON: fan on mode
CIRC: fan circulate mode
scale: temperature scale [F, C]
F: Fahrenheit
C: Celsius
The thermostat schedule is divided into 7 days with a maximum of 4 events per day. Access to the schedule is on a per-event basis. Each
event has a start time, heat and cool setpoint and a fan mode. When an assignment command is received, the specified event(s) are
automatically stored in non-volatile memory.
If an assignment command is received with a day of the week code [x] parameter of 7-9, the event [y] for each day corresponding to the
day of the week code [x] is configured with the parameters of the command (assuming correct syntax, etc.).
If a query command is received with a day of the week code [x] parameter of 7 or 9, the event configuration of Monday is sent; if the
parameter is 8, the event configuration of Saturday is sent.
If the thermostat is configured for 2 events per day, commands received with the event [y] parameter greater than 1 is ignored. If the
thermostat is configured with a Control Setup of Heat Only or Cool Only, only the respective setpoint is used in the command syntax.
This command is ignored if the controller type is set to humidistat or if the thermostat is configured as non-programmable. In addition,
commands with a day of the week code in conflict with the program format are ignored. (E.g. if the thermostat is configured with a program
format of 5/2 and a day of the week code of 0-6 is received, the command is ignored since the thermostat cannot program days individually in
the 5/2 program format.)
Integer values must be within the ranges specified. The schedule can be changed through the thermostat Program Screens. If the schedule is
changed at the thermostat, a C16 COS unsolicited message is issued (if C16 is ON). NOTE: if the schedule is changed at the thermostat, up to
4 COS unsolicited messages can be sent (one for each event in a day).
