Aprilaire E130 - Table of Contents; Specifications

SPECIFICATIONS ....................................................2
SAFETY INSTRUCTIONS .............................................3
WHOLE HOME DEHUMIDIFICATION.................................3
OPERATING THE DEHUMIDIFIER.....................................4
Energy Savings Tips .............................................4
MAINTENANCE ......................................................5
Cleaning the Filter...............................................5
Cleaning the Drain ..............................................5
PREPARING THE UNIT FOR INSTALLATION ..........................6
Repositioning the User Interface for the Application ..........7
Installing the Duct Collars ......................................7
INSTALLING THE DEHUMIDIFIER.....................................8
Dehumidier Location...........................................8
Leveling and Raising the Dehumidier .........................8
Installing a Condensate Pan Under the Dehumidier.........8
Installing the Drain ..............................................9
INSTALLING DUCTWORK............................................9
Ducting the Dehumidier Inlet and Outlet
to the HVAC System ............................................10
Ducting the Dehumidier Outlet to the HVAC System
with Dedicated Dehumidier Inlet Register ....................11
WIRING ............................................................ 12
Wiring to the HVAC System .................................... 12
Wiring to External or Remote Controls ..........................12
Wiring to a Float Switch. .........................................13
VENTILATION .......................................................14
ZONING THE DEHUMIDIFIER .......................................15
Required Components.........................................15
INSTALLER SETUP...................................................16
Setting Up Remote Control – Crawl Space/
Sealed Attic......................................................17
Setting Up Ventilation ...........................................17
Setting Up Zoning ...............................................17
Setting Up External Control .....................................17
ENABLING DEH W/AC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Applying an RH Offset...........................................17
STARTING UP THE UNIT AND SEQUENCE OF OPERATION..........19
Using the Dehumidier Control Only ..........................19
Using a Model 76 as a Remote Control .......................19
Using an External Control ......................................19
Two-Zone Operation ...........................................19
TROUBLESHOOTING ...............................................20
Diagnostic Codes ...........................................20, 21
Troubleshooting Guide......................................21, 22
SERVICE PARTS ....................................................23
LIMITED WARRANTY ...............................................24
Warranty Registration..........................................24
TABLE OF CONTENTS
SPECIFICATIONS
Model E130, E130C, and E130H
Unit Weight
98 lbs.
Capacity
80°F, 60% RH Conditions
130 pints per day @ 310 CFM
Power
115 VAC, Single Phase, 60Hz
8.3A operating current
Dehumidier Inlet Air Conditions
Dehumidication: 50°F – 104°F, 40°F dew point minimum
Ventilation: 40°F – 140°F, 0%RH – 99%RH (non-condensing)
Filter
MERV 8, washable
Airow
External Static Pressure (“WC) Airow (CFM)
0.0 310
0.2 270
0.4 225
0.6 175
NOTE: Rated capacity and current draw measured at 80°F/60% RH inlet conditions at 0.0 external static pressure.
