300XAC to an RS-232 communication bus.
RS-232 Interface
The protocol for interfacing and communicating using the RS-232 interface can
be found in section 9. Bus Remote Interface USB/GPIB/RS-232 of this manual.
Ethernet Interface
The Ethernet interface provides all of the function control of the standard
USB/RS-232 interface. Some commands are only exclusive to GPIB control.
Default Settings
The default settings for the Ethernet interface are as follows:
IP Setup: AUTO
IP Address: 010.000.000.000
Gateway IP: 000.000.000.000
Subnet Mask: 255.000.000.000
The source port number for the Ethernet Card in TCP connections is 10001.
11.4.1 Ethernet Card Setup
In order to setup the Ethernet card, the operator will need information from the
local network administrator. Please have your network administrator fill out the
required information on the next page and keep it for your records:
